Best Vernier Caliper Reviews

Vernier caliper is a type of caliper that makes use of the vernier scale to measure length, width, outside diameter, inside diameter, depth, and step. This vernier scale enables you to read in a resolution of 0.001″/0.02mm. It is commonly designed for a maximum measuring range of 6″ range. But you can also find the longer ranges such as 8″, 12″, 16″, etc.

Keep in mind that there are other 2 types of calipers that you can commonly find on the market to measure the same things: dial caliper and digital caliper.

One big advantage of using a vernier caliper is no battery needed to use it. You can take and use it every time you want without thinking of its battery. Besides, it’s relatively cheaper (not useless) compared to the dial and digital calipers. There is no LCD display. The reading is presented by calculating the main scale and the vernier scale.

This precision dimensional measuring instrument is used in many areas such as metalworking, woodworking, manufacturing, workshop, school, automotive, etc.

The best vernier caliper would at least have high accuracy, integrated construction, durable material, and clear to read the reading. If you are going to buy this instrument, perhaps, one of our top 10 vernier calipers below meet your requirements.

ProductRangeSpecDescriptionPrice
1. Mitutoyo
532-119
[Best Overall]

5"Resolution:
0.001"/0.02mm
Accuracy:
±0.03 mm
- Constant pressure
- High spec
- Great construction
- Dual reading
Check Price!
2. Mitutoyo
531-128

6"Resolution:
0.001″/0.02mm
Accuracy:
±0.03 mm
- Quick caliper
- High spec
- Great construction
- Dual reading
Check Price!
3. Mitutoyo
530-312

6"Resolution:
0.001″/0.02mm
Accuracy:
±0.03 mm
- High spec
- Great construction
- Dual reading
Check Price!
4. Starrett
125MEA-6

6"Resolution:
0.001″/0.02mm
Accuracy:
±0.001" & ±0.0015"
- High spec
- Great construction
- Dual reading
Check Price!
5. Mitutoyo
530-101

150
mm
Resolution:
0.05mm
Accuracy:
±0.05 mm
- Medium spec
- Great construction
- Metric only
- Affordable
Check Price!
6. Khcraft

6"Resolution:
0.001″/0.02mm
Accuracy:
unkown
- High spec
- Dual reading
- Affordable
Check Price!
7. Mitutoyo
530-316

6"Resolution:
1/128″ /0.05mm
Accuracy:
±0.05mm
- High spec
- Great construction
- Dual reading
- Fractional 1/128"
Check Price!
8. Fowler
52-058-016-0

6"Resolution:
0.001″/0.02mm
Accuracy:
Unkown
- High spec
- Dual reading
- Constant pressure
- Affordable
Check Price!
9. Fowler
52-057-004

4"Resolution:
0.001"
Accuracy:
Unkown
- High spec
- Great construction
- Pocket size
- Inch reading only
- Affordable
Check Price!
10. Mitutoyo
530-122

150
mm
Resolution:
0.02mm
Accuracy:
±0.03mm
- High spec
- Great construction
- Metric (mm) only
Check Price!

Top 10 Best Vernier Caliper Reviews 2021

1. Mitutoyo 532-119 Vernier Caliper with Fine Adjustment [Best Overall]

Best vernier caliper Mitutoyo 532-119When it comes to high-quality and accurate precision measuring tools, you could think of Mitutoyo’s products first. The same with finding the best vernier caliper, it’s not weird to prefer Mitutoyo vernier caliper first.

Mitutoyo 532-119 is what we find worth sharing to be the best vernier caliper overall. It’s a complete precision measuring tool that provides quality, great specification, dual reading, excellent construction, and fine adjustment carriage.

It has a 0-5″ range, 0.001″/0.02 mm resolution, and ±0.03 mm accuracy. The material is stainless steel which is good for corrosion-resistant. Incredibly, there are no screws that connect the scale and the sliding jaws. That means they are one integrated body. It is an expected construction.

What makes this caliper better than the others and becomes our best choice is its fine adjustment. This feature is very important to reduce errors during the measurement. It allows consistent pressure on the object being measured. Over pressing or too weak pressing will lead to questionable measurement. This feature, in turn, gives you more confidence of proper measurement.

Along with all of its advantages, you just need below $80 (at the time we checked) to purchase it. What a tempting choice. One disadvantage is no hard case. Compared to its advantages plus price, it’s not a vital issue.

Spec:

  • Range: 0-5 inch / 0-130 mm
  • Resolution: 0.02 mm /0.001 inch
  • Accuracy: 0.03 mm

Buy Now!

Pros:

  • Great specification
  • Comes with fine adjustment for reliable measurement (consistent pressure to the object being measured)
  • The price is affordable

Cons:

  • No hard case

2. Mitutoyo 531-128 Vernier Caliper with Spring-loaded Thumb

Mitutoyo 531-128Tightening and loosening the locking screw can slow your job. Taking multiple readings can be a time-consuming activity. It’s over now with Mitutoyo 531-128 thumb clamp.

As you can see, there is no locking screw. The spring-loaded thumb clamp replaces the function of the locking screw. Pressing it with your thumb allows sliding. Vice versa, depressing it makes the sliding scale won’t move. Further, this feature allows you to operate it single-handed.

For resolution, accuracy, and construction quality, it is no doubt. This model has 6″/150mm range and 0.001″/0.02mm resolution. As this is the high accuracy version, it supports accuracy down to ±0.03 mm. So, it’s not just about speed but also accuracy.

All in all, some people said that this vernier caliper is perfection. The combination of easy-to-use and high specification makes it suitable in most cases. Aside from that, you will get dual reading (mm and inch), etched markings, easy-to-read scale, and hardened stainless steel construction.

Spec (Based on Mitutoyo USA Ecatalogue):

  • Range: 0-6″/0-150mm
  • Resolution: 0.001″/0.02 mm
  • Accuracy: ±0.03mm

Buy Now!

Pros:

  • High-speed caliper; spring-loaded thumb for easy and fast measurement
  • Excellent specification
  • Great construction and durable
  • Etched markings

Cons:

  • Perhaps, a fine adjustment would make it more perfect

3. Mitutoyo 530-312 Vernier Caliper General Model

Mitutoyo 530-312

As you could browse Mitutoyo’s official catalog, Mitutoyo 530-312 is the general but high accuracy model. It serves you with a 6″ range, 0.001″ resolution for its inch reading, 0.02 mm for its mm reading, and ±0.03 mm for accuracy.

This excellent specification along with its Mitutoyo quality will serve you as a measuring tool for measurements of outside diameter, inside diameter, depth, and step. In addition to its benefits, it gives you dual reading, solid united construction, and hardened stainless steel material.

In case you need a certificate calibration, the option to purchase it with Certificate Traceability to NIST is available. Herewith, you will be sure that your caliper is calibrated using a standard that is traceable to NIST/world standards.

The drawback is no thumb wheel. There is no fine adjustment like the model 532-119. However, if you are well-practiced to give constant pressure, then this is a great choice to go.

Spec:

  • Range: 0-6″/0-150mm
  • Resolution: 0.001″ 0.02 mm
  • Accuracy: 0.03mm

Buy Now!

Pros:

  • Excellent specification for a vernier caliper
  • Solid and united construction
  • Dual reading: inch and mm

Cons:

  • No thumb roller

4. Starrett 125MEA-6 Vernier Caliper General Model

Starrett 125MEA-6Starrett is another excellent brand worth considering when you are looking for the best vernier caliper. Among the Starrett vernier calipers for sale, we are sure that this Starrett 125MEA-6 vernier caliper is one that you really figure out.

This model comes as a 6-inch range caliper that provides a dual reading of inch and mm. Respectively, the graduation of the inch and mm reading is 0.001″ and 0.02 mm. This graduation is also the resolution of this caliper.

According to the official site, it has two parts of accuracy. The accuracy of measurement in the range of 0-4″ is 0.001″. While the accuracy of measurement in the second range of 4-6″ inch is 0.0015″. Even though we commonly use the range of 0-4″, we should consider the second range as well.

Unlike the Mitutoyo 530-312 above, Starrett 124MEA-6 puts its inch markings in the lower scale while the mm markings in the upper scale. Like the other excellent vernier calipers, this caliper has the scale and the jaws as one body.

Buy Now!

Pros:

  • Good resolution and accuracy along the beam
  • Two measurement units
  • An integrated body of the moveable jaws and scale

Cons:

  • Like the other general models, it is not thumb roller

5. Vernier Caliper Metric Scale Model [Inexpensive Mitutoyo Model]

Mitutoyo 530-101If you are looking for a cheap Mitutoyo vernier caliper product, Mitutoyo 530-101 may be what you want. It’s priced under $50 at the last time of checking on the market. Though affordable, in terms of quality, it’s the same with other Mitutoyo vernier calipers.

The vernier face is clean and easy to read. There is no screw that invades the space that means high-quality construction. The face is also designed at an angle of 14° for easy to read and parallax error reduction. To hold the reading, the locking screw is available.

It supports measurements of outside diameter, inside diameter, depth, and step. The material is hardened stainless steel which is known more corrosion-resistant so that you can take advantage of it for a long time.

However, this one comes with a metric (mm) scale only. The metric markings are located in the lower scale. The specification for resolution and accuracy is also considered the lower one. This vernier caliper has a 150 mm range, 0.05 mm resolution, and ±0.05 mm. So, if you don’t require a high degree of accuracy, then this can be your wise choice.

Spec:

  • Range: 0-150mm,
  • Accuracy: ±0.05 mm,
  • Resolution: 0.05 mm

Buy Now!

Pros:

  • Affordable
  • Great quality
  • Excellent construction

Cons:

  • Provides metric reading only
  • Lower specification

6. Khcraft Vernier Caliper [Another Cheap Option]

KhcraftAn affordable cheap vernier caliper is not always bad. You may need the one that is friendly to your budget, still, it works for general purposes. If you don’t use it for accurate and precise measurements, this vernier caliper will be suitable for you.

It has a nice dual reading unit: metric (mm) and imperial (inch). The 0.02 mm graduation is on the lower scale, while the 0.001″ graduation is on the upper scale. The knurled thumb rest helps you to slide the scale.

However, the scale uses screws to integrate on the moveable jaws’ body. A high-quality construction vernier caliper has the scale and the moveable jaws integrated without screws. As the screw may lose and, as a result, generates even a small shake, you have to calibrate this caliper to assess its error.

All in all, this stainless steel vernier caliper is a nice option to use for general purposes. However, it’s not appropriate for professional use that requires high confidence in accuracy.

Buy Now!

Pros:

  • Nice to use for general purposes
  • Inexpensive option
  • Dual reading unit: inch and mm

Cons:

  • The scale and moveable jaws are not integral part; it’s screwed.

7. Mitutoyo 530-316 Vernier Caliper Metric & Fractional Scale [for Woodworking]

Mitutoyo 530-316

If you are a woodworker who mostly uses fractions instead of decimals, Mitutoyo 530-316 is the model that you are looking for. It comes with fractional markings on its upper scale.

The resolution of the fractional scale is 1/128″. This value is taken from the main scale and the second scale that has a graduation of 1/16″ and 1/8″ respectively.

There is also a decimal metric scale. It is on the bottom scale. This scale has a graduation of 0.05 mm. The accuracy is ±0.05mm.

You don’t need to worry about its durability. Made of stainless steel material, this Mitutoyo quality product will resist corrosion better than the steel-made caliper. The construction of scale and sliding jaws are also integrated without additional screws.

When you want to be free from battery use, or need something ready to use every time for your woodworking project, this vernier caliper is suitable to use. It comes with 2 external jaws, 2 internal jaws, and a rod. Therefore, it’s able to measure outside diameter, inside diameter, step, and depth.

Buy Now!

Pros:

  • Comes with fractional markings on the upper scale
  • Integrated construction of the moveable jaws and scale
  • 2 unit readings: fractional inch and decimal mm

Cons:

  • It’s not thumb roller, just a thumb rest

8. Fowler 52-058-016-0 Vernier Caliper [Fine Adjustment + Inexpensive Model]

Fowler 52-058-016-0Equipping with a fine adjustment feature may make your caliper expensive. Fowler 52-058-016-0 permits you to own it because of its affordable price.

This budget vernier caliper presents with a 0.001″ and 0.02 mm resolution. You will find the inch markings on the lower positioned scale, while the mm markings on the upper scale.

The fine adjustment lets you apply constant pressure to the clamped object. By this way, you are sure that the reading shows correctly.

Store it in the hard case when it’s not in use. Made from stainless steel material plus protected by a hard case, you have a double shield.

However, the construction makes use of screws to hold the vernier scale on the sliding jaws. This design allows the possibility of loosening screws. If the screws loosen, it won’t show exactly “0” reading when you zero it. Even further, you don’t generate any accurate results with it.

Buy Now!

Pros:

  • Budget caliper
  • Fine adjustment
  • High specification

Cons:

  • Weak construction on the scale that uses screws

9. Fowler 52-057-004 Mini Vernier Caliper

Fowler 52-057-004Fowler 52-057-004 is a short 4-inch range vernier caliper. This length lets you easily bring it anywhere. You could do it by simply putting it in the pocket. Many people buy this because of its size.

It is not only portable but also incredible quality construction. The despite low budget, it gives you an integrated body similar to the Mitutoyo and Starrett calipers do. Additionally, it takes advantage of stainless steel as the body material. This material is surely better than steel.

The scale is graduated in inch scale. It’s clean and easy to read since only provides inch markings. The resolution is also great which is 0.001″.

In summary, this unit can be your great consideration when looking for a budget vernier caliper. It delivers compactness, high resolution, integrated body, and affordability. The only thing that you should consider is the reading. Since it’s not dual reading, you have to convert it manually to an inch. If you don’t use mm, you should prefer it.

Buy Now!

Pros:

  • Pocket size
  • Excellent construction
  • High specification
  • Affordable

Cons:

  • Inch reading only

10. Mitutoyo 530-122 Vernier Caliper [High Accuracy Metric Scale Model]

Mitutoyo 530-122The last choice you could take into account is Mitutoyo 530-122 that comes with a metric scale only. In comparison with Mitutoyo 530-101, this model comes with higher specifications. So, when you need metric reading only with better accuracy, this one should be suitable for your need.

Buy Now!

Pros:

  • Higher resolution and accuracy
  • Fine construction

Cons:

  • No rolling thumb

Things to Consider Buying A Vernier Caliper

1. Resolution

Commonly, you will find vernier calipers on the market graduated in 0.001″ (0.0254 mm). If you get the lower one, you should expect a lower price. If you need a more accurate one than 0.001″, you may need a digital caliper such as Mitutoyo 500-196-30 that has 0.0005″ resolution and ±o.001″ accuracy.

2. Accuracy

Accuracy is one of the most important things in precision measuring instruments. It doesn’t necessarily mean if your caliper has great resolution, it has great accuracy. Keep in mind that resolution is the smallest reading that it can show, while accuracy is how close you are to the truth.

If your caliper’s resolution is 0.001″ and its accuracy is 0.001″, then it’s what you have to expect. In most cases, measuring instruments’ accuracy is similar to its resolution.  However, on the other hand, if your caliper’s resolution is 0.001″ and the accuracy is 0.05″, you have to less consider this option.

3. Certificate Calibration & NIST Traceability

If you want proof that your vernier caliper is accurate as described in its specification, you need to calibrate it using a reliable calibration procedure. In this case, you could hire a vernier caliper calibration service that is ISO 17025 accredited. The result of calibration is documentation that is called certificate calibration.

When you rely on ISO 17o25 accredited calibration service, your vernier caliper will be calibrated using a standard that is traceable to NIST. Herewith, your caliper will be NIST traceable eventually. The definition of the 1-inch measurement results generated by your caliper will be the same as the other 1-inch measurements across the globe. Finally, this NIST traceability makes up how reliable your measuring tool is.

4. Material

Is it constructed with steel, stainless steel, or hardened stainless steel? You are better off choosing the stainless one rather than the steel. The stainless steel is corrosion-resistant except for the low grades. It’s hard to know the material quality. Many companies only explain the material without further description of what stainless steel grade they are using. To solve this, you could read the customer reviews whether the caliper is easy to corrode or not.

5. Integrated Body

A high-quality vernier caliper will have the sliding jaws and scale face integrated as a single body. This construction design is meant for accuracy. The lower-quality construction uses screws to hold the scale on the sliding jaws.

When the screws are the joiner, the chance of play when you shake is real. This even, eventually, generates inaccurate measurement. The most common and easiest case is when you zero the caliper. Even though both the external and the internal jaws have clamped each other, you don’t see it shows zero reading.

6. Visibility

Visibility is important in vernier caliper because we take the reading manually. The chance of parallax error is high.

You have to get the scale that is etched rather than printed. The etched scale will last longer and not easily fade out compared to the printed one.

In addition to the visibility, you have to consider the numbers’ size. Some people that have poor vision may hard to see the numbers.

7. Inch or Millimeter (Imperial or Metric)

You cannot find all of the vernier calipers on the market with both inch (imperial) and millimeter (metric) unit reading on their scale. Some of them come either in inch or mm. Thus, you have to give a little care when selecting them. Further, this variation determines the price.

How to Use Vernier Caliper with Fine Adjustment

Conclusion

So far, the best vernier caliper brand is still Mitutoyo. They have various models you could choose from. The second brand is Starrett. And the third is Fowler.

People’s preferences may differ from each other. Some people demand accuracy, while others demand low-budget caliper for general purposes. In some cases, a fractional vernier caliper is a great option for woodworking. A short-range caliper will fit in the pocket and allow high mobility. Those requirements make us enlist the top 10 vernier calipers above as choices. Eventually, you are the one that determines.

However, if you still don’t have any requirements for what to buy first, you could buy Fowler 52-057-004 (inch graduation) or Mitutoyo 530-101 (mm graduation). Those two products are low-budget models but of great quality. If you know what you want, you should look for the most excellent vernier caliper. It is Mitutoyo 532-119 as we enlist the first position. Sometimes, a product comes without a description of its accuracy, in this case, you could assess it with a gauge block or caliper checker.

As you could read thoroughly here, the majority of vernier calipers have a 0.001″ or 0.02 mm resolution. If your project requires more accuracy than that value, you may need a micrometer.
